Insulation Piercing Tap Connectors 10KV Series
Feature:
1. Electrical properties is better, the elec-resistance reduced 30%
2. Good insulation performance
3. The installation torque is better than before, ease of application
|
Item No. |
Equivalent type |
Applicable voltage |
Applicable lead |
Main Dimensions |
Nominalcurrent |
BoltNumber |
Piercingdepth |
||
| A | B | H | |||||||
|
YJ10-240/150 |
YJ10-1 |
10KV 1KV GENERAL
|
150-240 |
160.0 |
140 |
112.5 |
476 |
2 |
4.5-6 |
|
YJ10-185/95 |
YJ10-2 |
95-185 |
152.0 |
140 |
112.5 |
476 |
2 |
4.5-6 |
|
|
YJ10-95/25 |
YJ10-3 |
25-95 |
144.5 |
140 |
95.2 |
257 |
2 |
4.5-6 |
|
|
YJ10-25/95
|
MIN |
25-95
|
62.0 |
102 |
85.0 |
276 |
1 |
4.5-6 |
|
General of insulation piercing connector(lPC)
1.1 Piercing connector, simple installation, need not strip the cable coat.
1.2 Moment nut, piercing pressure is constant, keep good electrìc connection and make no damage to lead
1.3 Self-seam frame,wetproof, waterproof,and anti-corrosion, extend the using life of insulated lead and connector
1.4 Adopted special connectìng tablet, apply to joint of Cu(Al) and Cu(Al) or Cu and Al
1.5 Small electric connecting resistance, connecting resistance less than 1.1 tìmes of the resistance of branch conductor wìth the same length
1.6 Special insulated case body, resistance to illuminatìon and environmental aging, the insulation strength can up to 12KV
1.7 Arc surface design,apply to connection with the same(different) diameter, wide connection scope(0.75mm2-400mm2)
Q:CAN YOU HELP US IMPROT AND EXPORT?
A:We will have a professional team to serve you.
Q:WHAT’S THE CERTIFICATES DO YOU HAVE?
A:We have certificates of ISO,CE, BV,SGS.
Q:WHAT’S YOUR WARRANTY PERIOD?
A:1 year in general.
Q:CAN YOU DO OEM SERVICE?
A:YES,we can.
Q:WHAT YOU LEAD TIME?
A:Our standard models are in stock ,as for big orders ,it take about 15 days.
Q:CAN YOU PROVIDE FREE SAMPLES?
A:Yes,please contact us to know the sample policy.
